With the growing demand for natural and healthy edible oils, the coconut oil market is expanding rapidly. For coconut oil processing plants, choosing an efficient, stable, and energy-saving copra oil press machine is essential. The copra screw oil press machine features advanced screw pressing technology and automated control systems, providing a complete solution for high-yield coconut oil production.
The copra screw oil press uses a continuous screw shaft to push copra into the pressing chamber, gradually compressing the raw material to extract oil. Coconut oil flows out through the oil outlet under pressure, while the pressed copra cake is discharged from the residue outlet. This efficient process makes the machine ideal for coconut oil processing equipment and coconut oil production lines.
Wash copra and crush to 2-3 cm particles;
Steam-roast at 70–90°C for 20–30 minutes to soften fibers and improve oil yield.
Multi-stage pressing cage compresses copra gradually;
Infrared heating ensures uniform temperature, keeping residual oil ≤8%;
Achieves oil yield of 55–60%, meeting high-output production requirements.
Crude oil is filtered using a vertical blade filter to remove impurities;
Stored in stainless steel tanks for further refining.
Model | Capacity | Residual oil rate of dry cake | Pressing shaft speed | Voltage | Required power | Dimension (L*W*H; mm) | Weight(kg) |
202-3 | 45～50T/24Hour | 13％ | 13RPM | 220/380V
| 30KW | 2900×1850×3640 | 5500 |
High Oil Yield: Screw pressing technology maximizes coconut oil extraction.
Easy Operation: Simple structure with automated control reduces labor costs.
Wide Application: Suitable for copra and various other oil-bearing materials.
High-Quality Oil: Extracted oil is golden, pure, and safe for consumption.
Continuous Production: Supports 24-hour operation, increasing plant efficiency.
Cleaning: Regularly clean pressing chamber and screw shaft to maintain hygiene.
Lubrication: Add oil to bearings and gears to reduce wear.
Inspection: Check operational status periodically to ensure stable performance.
Customized Solutions: Production lines designed based on raw material and capacity, supporting turnkey projects.
Global After-Sales: 24-hour technical support, on-site training for operators, ensuring stable operation.
Professional Technical Guidance: From machine selection to process optimization, we provide expert advice throughout.
Contact QIE Group now to get your tailored Copra Screw Oil Press Machine solution, and make your coconut oil production more efficient, stable, and competitive!
